NGC 40 in CTA1 - Planetary Nebula and Supernova Remnant

CTA1 is a very dim supernova remnant located within the constellation Cassiopeia, approximately 4600 light-years away. This celestial object has garnered substantial attention from astronomers due to its complex structure and puzzling characteristics.

A point source within CTA1 was presumed to be a pulsar. However, despite these expectations, no radio pulses were ever detected. This was until NASA's Fermi Space Telescope uncovered that it pulses at gamma-ray energies. This peculiar source marks the inaugural discovery of a unique class, named "dark pulsars" (rotating neutron stars that exclusively emit pulses in the form of high-energy radiations). These dark pulsars might elude detection in radio or visible light if their emissions are confined to a narrow beam, that is unseen from Earth. The study of gamma-ray properties exhibited by pulsars offers invaluable insights into the physics governing the emission regions on neutron stars.

A little right from the center of the image lies the planetary nebula NGC 40. One of the remarkable features of NGC 40 is its bipolar structure. The nebula's lobes extend symmetrically in opposite directions, forming a visually striking bow-tie shape. This distinctive morphology is believed to result from the complex interplay of stellar winds and magnetic fields during the star's evolution. The shaping of planetary nebulae, including NGC 40, remains an area of active research, as astronomers seek to unravel the underlying mechanisms responsible for their diverse forms.

The goal in creating this image was to combine the advantages of short and long exposures. Thus, in the case of NGC 40, to achieve good sharpness, only 0.5s per image were exposed. The sharpened image was then combined with the long exposures in H-Alpha.

Photographed from Schriesheim and Bamberg, Germany under Bortle 5 conditions.

  • Category

    Planetary Nebula / Supernova Remnant

  • Coordinates

    RA 23h 59m 00s
    DEC +62° 24′ 00″

  • Distance

    ~4.600 ly (CTA1)
    ~3.500 ly (NGC 40)

  • Apparent Mag

    ---

  • Equipment

    TS ONTC8 200/800 Astrograph
    Dobson 305/1500mm Skyliner FlexTube
    iOptron CEM70G
    QHY 294m pro
    ZWO ASI 178mm

  • Exposure

    L: 60 x 180 s
    L: 28800 x 0.5s
    R: 30 x 180 s
    G: 30 x 180 s
    B: 30 x 180 s
    Ha: 135 x 300 s
    OIII: 72 x 300 s
    Total Integration: 28.8 h

  • Publication Date

    14.01.2024
